Air Cooler which can drop the temperature up to 10 Degrees during summer.

Country Of Origin : India

  • Additional information

    Evaporative cooling systems, also known as swamp coolers or desert coolers, are devices that cool air through the evaporation of water. They work on the principle that when water evaporates, it absorbs heat from the surrounding air, thus cooling it down. Here's how they typically work:


    Basic Components: An evaporative cooling system typically consists of a water reservoir, a pump to circulate water, a cooling pad or media, and a fan.


    Water Circulation: Water from the reservoir is pumped onto the cooling pad or media, which is usually made of a porous material such as cellulose. The pad becomes saturated with water.

    Air Flow: A fan draws warm air from outside through the saturated cooling pad. As the air passes through the wet pad, it evaporates some of the water, which cools the air. The now-cooled air is then blown into the space to be cooled, such as a room or building.

    Evaporative Cooling Process: As water evaporates from the cooling pad, it absorbs heat from the incoming air, reducing its temperature. The cooled air is then distributed throughout the space, providing a comfortable environment.


    Humidity Control: Evaporative coolers add moisture to the air as part of the cooling process. While this can be beneficial in dry climates where air tends to be very dry, it may not be ideal in humid climates where adding more moisture to the air could lead to discomfort or indoor air quality issues.


    Energy Efficiency: Evaporative cooling systems tend to be more energy-efficient than traditional air conditioning systems, especially in hot, dry climates. They use less electricity because they don't rely on energy-intensive refrigeration cycles like air conditioners.

    Overall, evaporative cooling systems can be an effective and energy-efficient cooling solution, particularly in arid regions. However, their effectiveness can be limited in areas with high humidity levels, and they may require regular maintenance to prevent issues such as mineral buildup on the cooling pads.



    Advance Information*

    Overview of the Air Cooler

    The air cooler is an advanced climate control solution designed to drop the temperature by up to 10 degrees during the scorching summer months. Employing the principle of evaporative cooling, this air cooler transforms hot, dry air into a refreshing breeze, making it a sustainable and energy-efficient alternative to traditional air conditioning systems. Ideal for arid regions, this device not only cools the air but also enriches it with moisture, promoting a more comfortable living environment.

    Principle of Operation

    Evaporative Cooling Explained

    Evaporative cooling, also known as swamp or desert cooling, harnesses the natural process of water evaporation to absorb heat from the surrounding air. When water evaporates, it takes up heat from the air, leading to a drop in air temperature. The main components of an evaporative cooling system include a water reservoir, a pump, a cooling pad or media, and a fan.

    Technical Components

    Water Reservoir

    The water reservoir serves as the primary source of water for the cooling system. It ensures a continuous supply of water to the cooling pads, facilitating the evaporation process. This reservoir is meticulously designed to sustain adequate water levels, ensuring persistent cooling without interruptions.

    Pump System

    The pump system is responsible for transporting water from the reservoir to the cooling pad or media. Configured to operate seamlessly, it ensures that the cooling pads remain saturated throughout the functioning period. This continuous circulation is crucial for maintaining the evaporative cooling cycle.

    Cooling Pad or Media

    The cooling pad is constructed from porous materials, such as cellulose, which become thoroughly soaked with water. As warm air is drawn through these wet pads by the fan, the water evaporates, absorbing heat from the air and effectively cooling it. The pads are designed to maximize water absorption and enhance the rate of evaporation.

    Fan Mechanism

    The fan draws in warm air from the surrounding environment, channels it through the saturated cooling pad, and then disseminates the now-cooled air into the space being cooled. The fan ensures efficient airflow, augmenting the cooling efficiency and distributing the cooled air uniformly.

    Evaporative Cooling Process

    1. Water Circulation: Water is drawn from the reservoir by the pump and distributed evenly over the cooling pads.
    2. Air Flow: The fan pulls in warm air from outside, directing it through the wet cooling pads.
    3. Evaporation and Cooling: As the warm air traverses the wet pads, water on the pads evaporates, absorbing heat from the air, which results in a cooler air output.
    4. Humidity Introduction: The cooled air, now carrying additional moisture from the evaporative process, is blown into the room, providing a cooling effect while increasing humidity levels.

    Humidity Control

    While the added moisture in the air can be advantageous in dry climates, enhancing comfort and preventing issues like dry skin and eyes, it can be less desirable in already humid environments. In regions with high humidity, this added moisture could lead to a feeling of stuffiness or indoor air quality dilemmas. Therefore, the air cooler is particularly optimized for use in arid and semi-arid climates.

    Energy Efficiency

    One of the most remarkable benefits of evaporative cooling systems is their energy efficiency. Unlike traditional air conditioning units that rely on power-intensive refrigeration cycles, the air cooler operates on the simple mechanics of water evaporation. This significantly reduces electricity consumption, making it an eco-friendly and cost-effective cooling solution. Especially suited to hot, dry regions, it presents a sustainable way to maintain comfortable indoor temperatures.

    Maintenance and Longevity

    Routine Maintenance

    Regular maintenance is essential to ensure the optimal performance and longevity of the air cooler. The main areas of focus include:

    • Water Reservoir: Periodically clean to prevent algae and mineral buildup. Ensuring that the water remains uncontaminated is crucial for both efficiency and hygiene.
    • Cooling Pads: Regular inspection and cleaning of the cooling pads to remove any accumulated minerals or dirt. These pads should be replaced periodically for sustained efficiency.
    • Pump and Fan: Check and service the pump and fan to ensure they are functioning correctly. Lubrication and cleaning of these components can prevent mechanical wear and tear.

    Preventive Measures

    Implement preventive measures to minimize issues like mineral buildup on cooling pads, which can hamper the evaporation process and decrease cooling efficiency. Using treated or softened water can reduce the risk of mineral accumulation.

    Design and Functionality

    Ergonomics

    The air cooler is designed with user convenience in mind. With an intuitive control panel, users can easily adjust settings for fan speed, water flow, and cooling intensity. The design also includes easy-access panels for straightforward maintenance and refilling.

    Portability

    Equipped with caster wheels, the air cooler offers remarkable portability, enabling users to move it effortlessly across different rooms or spaces. This feature ensures that you can enjoy cool and comfortable air wherever you need it.


    *Disclaimer: This additional description has been automatically generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
