The Butt Weld Long Radius 90 Degree Elbow offered by Newzel Industries is an essential component in piping systems, designed to facilitate smooth transitions in pipelines with a 90-degree turn. Manufactured to the highest standards, these elbows ensure low pressure drop across the system, making them a preferred choice for industrial applications. Available in a wide range of materials including various grades of Stainless Steel, Carbon Steel, Monel, Nickel, Inconel, Incoloy, Hastelloy, Titanium, Alloy Steel, Duplex, and Super Duplex Steel, our Butt Weld Long Radius 90 Degree Elbows can cater to diverse operational needs. Notably, these elbows can also be customized to fit specific piping layouts, allowing for precise installation and effective fluid flow management. With a centerline radius of 1.5 times the nominal pipe diameter, they are designed to optimize performance without compromising structural integrity. Furthermore, long tangent variations provide extended options for more complex piping configurations.
Key Features
| Features | Description |
|---|---|
| Material Options | Available in Stainless Steel, Carbon Steel, Monel, Nickel, Inconel, Incoloy, Hastelloy, Titanium, Alloy Steel, Duplex & Super Duplex Steel |
| Design Type | Butt weld for seamless integration into piping systems |
| Bend Radius | Centerline radius is 1.5 times the nominal pipe diameter |
| Pressure Drop | Optimized for low pressure drop in piping systems |
| Customization | Can be cut at lesser degrees as required in piping layout |
| Long Tangent Elbow | Options available with a straight extension at one end |
| Attributes | Description |
|---|---|
| Degree of Bend | 90 Degrees |
| Pipe Diameter Range | Available in various nominal pipe sizes (NPS) |
| End Types | Butt weld ends |
| Weight Options | STD weight available upon request |
| Applications | Used in various piping systems across industries such as oil and gas, chemical, water treatment, and more. |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
Country Of Origin: India
We at Newzel Industries are manufacturers & exporters of Pipe fittings, Flanges & Forgings in various grades as well as stockiest for Pipes/Sheets and Round bars. MSS SP-43 only covers stainless steel buttweld fittings made for use with Schedule 5S and 10S pipe and Stub Ends suitable for use with Schedule 40S pipe, as defined in ASME B36.19. The dimensions and dimensional tolerances defined in MSS SP-43 are substantially the same as those in ASME B16.9 specifications from NPS 1/2 - NPS 24. Except with regard to the outside diameter at the bevel. They're Available in all grades of Stainless Steel, Carbon Steel, Monel, Nickel, Inconel, Incoloy, Hastelloy, Titanium, Alloy Steel, Duplex & Super Duplex Steel.
Butt weld long radius 90 degree elbow is used for 90 degree turn on piping in butt weld piping system. Long radius elbows are preferred due to their low pressure drop. They can also be cut at a lesser degree if required in piping layout. Their centerline radius is 1.5 times the nominal pipe diameter. 90-Degree elbows with a straight extension at one end (long tangent) are still available in STD weight if required. a long 90 degree elbow has the centerline of the elbow at 1.5 x NPS from the elbow end. The 3R elbow has a centerline at 3 x NPS from the elbow end.
