GPN SERIES 300 MM - 450 MM

Improved aesthetics

Extruded al. Carcase

Pressure diecast brackets

Double sealed prelubricated bearings


Major Applications

Desert Cooling or Evaporative Cooling

Transformer Cooling, Condenser Cooling
Chiller

Ventilation

Axial Flow Fans

Range : Air flow from 1000 m3/hr to 350000 m3/hr with Static pressure from Free flow to 135 mm wg subject to a maximum Motor rating of 75KW.

Sweep : 12"" to 75""

Speed : 725 to 2950 rpm

Impeller : Die Cast Aluminum alloy having Aerofoil blades with adjustable angle


Man Cooler

Size : 19"" to 48"" ( 5 Sizes)

Type : Tubular, Pedestal, Bracket Type

Air Qty. : 22000 M3/hr to 74500 M3/hr at 10 times Blade Sweep

Speed : 960 to 2900 Rpm




"
Feature*
  • Range: Air flow from 1000 m3/hr to 350000 m3/hr
  • Speed: 725 to 2950 rpm
  • Sweep: 12"" to 75""
  • Impeller: Die Cast Aluminum alloy with Aerofoil blades
  • Motor Rating: Maximum 75KW
  • Man Cooler Size: 19"" to 48""
  • Man Cooler Type: Tubular, Pedestal, Bracket Type
  • Static Pressure: Free flow to 135 mm wg
  • Man Cooler Speed: 960 to 2900 Rpm
  • Man Cooler Air Qty.: 22000 M3/hr to 74500 M3/hr

Country Of Origin : India

  • Additional information

    Industrial Fans are designed to provide efficient air circulation and ventilation in various industrial settings. These fans offer reliable performance and durability, making them suitable for applications such as cooling, exhaust, and air movement in manufacturing and processing environments.
    We are pleased to inform that we have all the regular rating motors in-stock and non-stock motors can be made available within short and flexible delivery period as per customer needs. We assure you our best competitive pricing and commercial terms. We Also Deal In Oxford, Marathon Electric, Crompton & Greaves, Bharat Bijlee, Kirloskar, Abb, Baldor Etc. We Are Glad To Inform You That We Are Already On Vendor List Of Many Big Corporate House & Mnc'S.

    Advance Information*

    Industrial Fans: Advanced Solutions for Diverse Applications

    Industrial fans are critical components in various environments that require efficient air movement and cooling solutions. Significantly contributing to processes such as evaporative cooling, transformer cooling, condenser cooling, chillers, and ventilation, these fans improve environmental conditions and machinery performance. This comprehensive description delves into the specifics of several industrial fans, focusing on the GPN SERIES and other types, including axial flow fans and man coolers.

    GPN SERIES Industrial Fans (300 MM - 450 MM)

    The GPN SERIES of industrial fans is renowned for its improved aesthetics and robust construction. These fans are ideal for applications that demand consistent performance and durability.

    Key Features and Specifications: - Aesthetics: Designed with modern, sleek aesthetics that allow these fans to integrate seamlessly into any industrial setting. - Construction: Made with an extruded aluminum carcass for optimal strength and longevity. - Brackets: Employ pressure die-cast brackets, ensuring stability and rigidity. - Bearings: Utilize double-sealed, pre-lubricated bearings which contribute to the low maintenance and extended life of the fans.

    Applications: - Desert Cooling: Ideal for evaporative cooling in arid regions, providing efficient temperature control. - Transformer Cooling: Ensures that electrical transformers maintain optimal operating temperatures. - Condenser Cooling: Vital for enhancing the performance of condensers in HVAC systems. - Chiller Applications: Supports the efficient operation of industrial chillers. - Ventilation: Excellent for general ventilation purposes, ensuring a steady flow of fresh air.

    Axial Flow Fans

    Axial flow fans are engineered to deliver high volumes of air efficiently, making them indispensable in environments where substantial airflow is necessary.

    Range: - Air Flow: Capable of delivering air flow from 1,000 m³/hr to 350,000 m³/hr. - Static Pressure: Covers pressures from free flow to 135 mm wg, adaptable to various industrial needs. - Motor Rating: Operates with motor ratings up to 75 KW, suitable for extensive and demanding operations.

    Sweep: - Size: Available in sizes ranging from 12 inches to 75 inches, covering a broad spectrum of application requirements.

    Speed: - RPM: Ranges from 725 to 2,950 RPM, providing flexibility in speed and efficiency based on specific application needs.

    Impeller: - Material: Constructed from die-cast aluminum alloy. - Design: Features aerofoil blades with adjustable angles to optimize air delivery and efficiency.

    Man Cooler Fans

    Man cooler fans are designed to offer high-volume air output, perfect for cooling personnel or machinery in industrial settings.

    Size: - Range: Available in sizes from 19 inches to 48 inches, offering choices to match specific cooling demands. - Types: Comes in several types, including tubular, pedestal, and bracket types to suit various installation requirements.

    Air Quantity: - Output: Delivers air quantities ranging from 22,000 m³/hr to 74,500 m³/hr at ten times the blade sweep, ensuring substantial cooling capacity.

    Speed: - RPM Range: Operates at speeds from 960 to 2,900 RPM, providing versatile options for different cooling scenarios.

    Fan Construction and Design

    Industrial fans are built to withstand rigorous conditions and continuous operation. The usage of materials like extruded aluminum and die-cast parts ensures that these fans not only perform efficiently but also endure the test of time.

    Materials: - Aluminum Alloy: Commonly used for impeller blades due to its lightweight yet robust properties, enhancing the overall performance of the fans. - Extruded Aluminum Carcass: Provides a solid framework that resists wear and tear even in challenging environments.

    Enhanced Bearings

    Double-Sealed Prelubricated Bearings: - Durability: These bearings are designed to be maintenance-free, sealed to prevent contaminants from affecting their performance. - Prelubricated: Ensures smooth operation from the moment of installation, reducing downtime and maintenance costs.

    Versatility in Application

    Industrial fans are designed to tackle a range of tasks across different sectors. From cooling massive transformers to providing sufficient ventilation in large industrial spaces, the flexibility and variety of industrial fans make them crucial in maintaining optimal conditions.

    Major Applications: - Evaporative Cooling: Particularly critical in manufacturing plants and warehouses where traditional air conditioning might be impractical or too costly. - Transformer and Condenser Cooling: Essential for maintaining the efficiency of electrical systems and HVAC units. - Chillers: Helps in the precise control of temperatures in processes that require stability and consistency. - General Ventilation: Critical
