As the first megapixel scanner on the market, the Stationary 1D and 2D Barcode Scanners FR4080 read 1D and 2D barcodes, including Aztec, with speed and ease. Equipped with a switch to toggle between paper and screen modes you are assured to have the best-optimized reading every time. With user-friendliness being at the forefront of POS systems, the Koi II features soft illumination with a 10-degree tilt that ensures comfort for both employees and customers. Combined with its superior performance and level of comfort, the FR4080 Koi II is the perfect addition to any POS system.
It is the first presentation scanner on the market that includes a megapixel camera and is capable of reading even the most complex codes. This makes it the perfect solution for applications like POS systems in retail and pharmacy, ticket verification and more.
The IR sensor in the FR4080 Koi II enables the speedy capture of any barcode presented to it, markedly increasing output and productivity.
As the first megapixel scanner on the market, the Stationary 1D and 2D Barcode Scanners FR4080 read 1D and 2D barcodes, including Aztec, with speed and ease. Equipped with a switch to toggle between paper and screen modes you are assured to have the best-optimized reading every time. With user-friendliness being at the forefront of POS systems, the Koi II features soft illumination with a 10-degree tilt that ensures comfort for both employees and customers. Combined with its superior performance and level of comfort, the FR4080 Koi II is the perfect addition to any POS system.
It is the first presentation scanner on the market that includes a megapixel camera and is capable of reading even the most complex codes. This makes it the perfect solution for applications like POS systems in retail and pharmacy, ticket verification and more.
The IR sensor in the FR4080 Koi II enables the speedy capture of any barcode presented to it, markedly increasing output and productivity.
As the first megapixel scanner on the market, the Stationary 1D and 2D Barcode Scanners FR4080 read 1D and 2D barcodes, including Aztec, with speed and ease. Equipped with a switch to toggle between paper and screen modes you are assured to have the best-optimized reading every time. With user-friendliness being at the forefront of POS systems, the Koi II features soft illumination with a 10-degree tilt that ensures comfort for both employees and customers. Combined with its superior performance and level of comfort, the FR4080 Koi II is the perfect addition to any POS system.
It is the first presentation scanner on the market that includes a megapixel camera and is capable of reading even the most complex codes. This makes it the perfect solution for applications like POS systems in retail and pharmacy, ticket verification and more.
The IR sensor in the FR4080 Koi II enables the speedy capture of any barcode presented to it, markedly increasing output and productivity.
Performance
Image Sensor 1280×800 CMOS
Illumination White LED
Depth of Field EAN13 (13mil) 5-195mm
Depth of Field QR (15mil) 5-165mm
Minimal Print Contrast 25%
Scan Angle Roll 360°
Scan Angle Pitch ±50°
Scan Angle Skew ±45°
Field of View Horizontal 51°
Field of View Vertical 32°
Motion Tolerance 2.5m/s
Data capture
1D EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code 128, Code 93, ITF-6, ITF-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5, GS1 Databar, Code 39, Code 11, MSI-Plessey, Plessey, etc.
2D PDF417, Data Matrix, QR Code, Micro QR Code, Aztec, etc.
Physical
Dimensions (mm) 83(W)x81(D)x148(H)mm
Weight 293g
Interfaces RS-232, USB
Notifications Beep, LED indicator
Input Voltage 5VDC±5%
Current @ 5VDC Operating 219mA (typical)
Power Consumption 1041mW (typical)
Environmental
Operating Temperature -20°C to 60°C
Storage Temperature -40°C to 70°C
Humidity 5% to 95% (non-condensing)
Electro Static Discharge (ESD) ±14 kV (air discharge), ±8 kV (direct discharge)
Drop 1.2m
Sealing IP52
Certifications
Certifications FCC Part15 Class B, CE EMC Class B
Shipping
Country Of Origin : India
Desktop 2D barcode Scanner with 1280 x 800 CMOS image sensor for superior motion tolerence,IP52 rated seal protection agaisnt dust & water IR sensor equipped , 1.2 mtr drop protection,armed with patented 6th gen technology 1280 x 800 CMOS image sensor
RS-232,USB Interfaces, 293g Weight
83x81x148 mm Dimensions
The Newland FR4080 Koi II 2D USB Tabletop Barcode Scanner stands out as a revolutionary device in the barcode scanning industry, offering unmatched performance and user-friendly features. Targeting the retail, pharmacy, and ticket verification sectors, this scanner combines advanced technology with ergonomic design to deliver seamless and efficient barcode scanning solutions.
The FR4080 Koi II boasts several innovative features that streamline the barcode scanning process. These features include:
Megapixel Camera: As the first presentation scanner on the market equipped with a megapixel camera, the FR4080 Koi II can decode the most complex 1D and 2D barcodes with remarkable speed and precision.
Switch Between Paper and Screen Modes: A convenient switch allows users to toggle between paper and screen modes, ensuring optimized reading performance in any situation.
Sophisticated Illumination: The Koi II is designed with soft white LED illumination and a 10-degree tilt. This feature enhances comfort for both employees and customers, reducing eye strain and making long work shifts more manageable.
IR Sensor for Speedy Capture: An integrated IR sensor detects barcodes quickly, which increases output and productivity. The scanner reacts swiftly whenever a barcode is presented, making it extremely efficient in high-traffic environments.
The inclusion of a megapixel camera in the FR4080 Koi II marks a significant leap forward in the capability of barcode scanners. This advanced camera enhances the scanner’s ability to read high-density and complex barcodes that are often used in various industries. Whether dealing with traditional 1D barcodes or more intricate 2D barcodes such as QR Codes and Aztec codes, the FR4080 Koi II handles them with ease.
One of the standout features of the FR4080 Koi II is its ability to switch seamlessly between paper and screen modes. This functionality is particularly useful in retail
