Hikvision DS-2CE1AC0T-IT3F Turbo HD 1MP Camer Bullet Camera

Advance Information*

Overview

The Hikvision DS-2CE1AC0T-IT3F Turbo HD 1MP Camera is an ideal choice for robust and reliable surveillance solutions. With a host of features designed for clear imaging and versatile functionality, this outdoor EXIR bullet camera is built to provide high-quality video under a variety of conditions. The device is purpose-built for utmost performance and durability, making it a prime candidate for securing both residential and commercial properties.

Key Features

Exceptional Image Quality

• HD720p Resolution
  • Capable of delivering high-definition video with a resolution of 1280 x 720 pixels, the camera ensures crystal-clear imagery.
• 1MP CMOS Sensor
  • Equipped with a 1 megapixel CMOS sensor that captures precise details and offers superior image quality even in challenging lighting environments.

Advanced Illumination

• EXIR Technology
  • Features a single EXIR LED, providing enhanced infrared contrast and minimizing overexposure in dark areas.
• 40 Meter IR Range
  • The infrared capabilities extend up to 40 meters, ensuring long-distance night vision and surveillance in low-light conditions.
• Smart IR
  • Smart IR is designed to optimize illumination and reduce overexposure in near-field locations, enhancing the overall image quality.

Versatile Video Output

• Multi-format Video Output
  • Supports TVI, AHD, CVI, and CVBS video output formats, allowing seamless integration with most existing surveillance systems and providing flexibility for upgrades.

Robust Design

Weather-Resistant Build

• IP66 Rating
  • The camera sports IP66 weatherproofing, making it resistant to dust and heavy rains, suitable for outdoor installations where harsh weather conditions are concerned.
• Wide Operating Temperature Range
  • Capable of operating efficiently within a temperature range of -40°C to 60°C, this camera is designed to withstand extreme climate variations.

Durable Construction

• Outdoor EXIR Bullet
  • Constructed with durability in mind, the Hikvision DS-2CE1AC0T-IT3F thrives in outdoor surveillance scenarios, providing resilience and extended operational life.

Enhanced Lens Options

• 8mm & 12mm Lens Variants
  • Offers lens options with both 8mm and 12mm focal lengths, facilitating different field-of-view requirements and allowing for more focused or wider-area monitoring based on specific needs.

Technical Specifications

| Parameter | Specification | |------------------------------|----------------------------------------| | Resolution | HD720p (1280 x 720) | | Image Sensor | 1MP CMOS Sensor | | IR LED | 1 pcs EXIR LED | | IR Range | 40 meters | | Video Output | TVI, AHD, CVI, CVBS | | Illuminance | 0.1 Lux/F1.2 | | Day/Night | ICR (Infrared Cut Removable) | | Power Supply | 12 VDC | | Weatherproof Rating | IP66 | | Operating Temperature | -40° to 60°C | | Lens Options | 8mm or 12mm |

Imaging Performance

Day/Night Capability

• ICR (Infrared Cut Removable)
  • Integrates an Infrared Cut Filter Removal mechanism, which ensures superior color fidelity during the day and enhanced sensitivity at night.
• Low-light Performance
  • Achieves reliable imaging performance with a minimum illumination of 0.1 Lux at F1.2 aperture, providing quality footage even under low light conditions.

Applications

The Hikvision DS-2CE1AC0T-IT3F Turbo HD 1MP Camera is suitable for a variety of security applications, including: - Perimeter Security - Ideal for monitoring the borders of a property, benefiting from the long IR range and robust build. - Public Area Surveillance - Secures open spaces like parks or squares, where durable and reliable performance is critical. - Commercial Installations - Deployed around commercial premises to safeguard assets and property with precise and clear surveillance footage. - Residential Monitoring - Perfect for home surveillance purposes, ensuring 24/7 security with its advanced features and durable design.

Installation and Connectivity

Easy Integration

• Multi-format Compatibility
  • The camera’s compatibility with multiple video formats (TVI, AHD, CVI, CVBS) ensures easy integration with various existing systems, whether for new or upgraded installations.

Power Supply

• User-friendly Power Options
  • Operates on a 12 VDC power supply, facilitating easy and flexible installation
