98 results for

"Agricultural Machinery Equipment"

Electric Winches

Electric Winches

Motor CROMPTON/ GEC/ KIRLOSKER" Make Slipring Crane Duty Motor 960 RPM, 440 Volt, 3 phase, 1 Hr. rated 40% ED as per IS: 325 having 'B' Class insulation. Drum Made from Rolled steel as per IS:226 of adequate thickness with side flange. Drum running on Bearing to take adequate rope length. Shaft Forged from EN-8 steel machine fitted with Drum. Chassis: Fabricated from joist of adequate size as per IS: 226 to take all shocks. All the stands on the chassis are Boxed type. Reduction 1st Reduction: through Elecon/Radicon make worm reduction Gear Box totally enclosed running on oil. 2nd Reduction: through open machine cut Gear from carbon steel & pinion made of Alloy Steel duly heat treated. Break Electro Magnetic Hydraulic Thruster Brake of reputed make. Mechanical Bend Brake with screw system with Ferrodo Brake lineing. Extra safety Ratchet pawl arrangement on the side of the drum for not moving the drum in opposite direction for extra safety. Coupling We will provide flex. Brake Drum coupling on the out put of motor & Input of Gear Box. Flex. coupling pin type on the output shaft of the Gear Box & In put shaft of the pinion. Controls Drum controller of TAC Make 5/7 steps. Forward & Reverse mtio. Control panel in sheet in sheet metal Box for dust, heat & water resistance containing of : Isolator Overload Relay Contector Single phase preventer FuseHrc. Amp. Meter Voilt Meter (h) Neon Lamp Push Button for start & Stop Resistance Box 10 Minute rating. Wiring & Pairrting We will provide all wiring from weather proof ar mured copper cable of adequate size & the Winch will be painted by two coats of primer & Two coats of Grey paint. Operator seat We will provided operator seat by the side of controls. Note Speed of 5 Ton & 10 Ton winch is 8/1OMTS per minutes. General Description SKID Frame Type- Frame made out of heavy steel sections M.S. Drums M. S. Gear & Pinion. Teeth Cut on Gear Hobbing Machine for Perfect Pitch. Reduction through Gear Box and Bull Gear & Pinion. Hydraulic Thrustor Brake ElectroMagneticBrake Electro Magnetic Brake. Manual Brake Carbon Steel Shaft A Safety Ratchet System All controls within reach of operator. Variable Speed Motor. Load & Speed as per Requirement of the Customer. Detail required for submission by Customer Rope pull in Tons ( Capacity) Speed required Mtr./per Min. Rope size & Length required on Drum. Available Elec. Current supply. Description of Application. Other accessories required with.

Price on Request
Earth Auger Trolley Type

Earth Auger Trolley Type

It seems like you're describing the specifications and features of an Earth Auger machine. Let me break down the terms and features you mentioned: Earth Auger: An Earth Auger is a tool or machine used for drilling holes in the ground. It's commonly used in gardening, landscaping, construction, and other industries. Centrifugal Friction Clutch Transmission: This type of transmission relies on centrifugal force to engage and disengage the clutch. As the engine's speed increases, the clutch engages to transfer power to the auger, and it disengages at lower speeds. Single Operation Type: This likely refers to a simple one-lever operation to engage the Earth Auger. Pulling a lever or pressing a button would typically activate the auger's drilling action. Two-Stroke Air-Cooled Engine: This describes the type of engine used in the Earth Auger. A two-stroke engine is known for its simplicity and is often used in smaller machines like augers. It requires a mixture of oil and gasoline for fuel and relies on air cooling for temperature regulation. Ideal Speed 3000 +/- 150 RPM: This specifies the desired operating speed of the engine. The engine should ideally run at around 3,000 revolutions per minute (RPM) with a tolerance of plus or minus 150 RPM. Ignition Type Electronic (CDI)/Magneto: This indicates the ignition system used in the engine. CDI (Capacitor Discharge Ignition) and magneto are two common types of ignition systems in small engines. CDI systems use capacitors to store and discharge energy to create sparks for ignition, while magnetos generate sparks through the rotation of a magnet. It's worth noting that these specifications are typical for small engines used in equipment like Earth Augers. These features ensure efficient operation and ease of use for drilling holes in various soil conditions.

Price on Request
